There was a long delay in booting screen of MSI H61M-P23 (B3) mainboard when the CarPC JoyCon Exr was connected. This Boot trouble with CarPC JoyCon Exr and Intel H61/H76 chipset mainboard(include Asus P8H67-I Deluxe, MSI H61M-P23) has solved. Firmware later than 120331 version and JoyCon Expolorer later than 120331 version is
How to
[CPJexr]Test of CarPC JoyCon Exr input wires
When you receive CarPC JoyCon Exr, you may want to to test it. This is the simple way of test. When you connect CarPC JoyCon Exr with USB cable, Windows will install drivers. Install JoyCon Explorer in the CD-ROM and run it. Connect the input wires into the channel A like this picture. And short-circuit
[CPJexr]Ford Mondeo MK2 96-00 Radio controller wiring for car pc
Knowledge Note KN1045 CarPC JoyCon Exr(Ex) Ford Mondeo MK2 96-00 Radio controller wiring for car pc Because Ford Mondeo 96-00 Radio controller is not resistive, you need a Resistive Button PCB that converts it into resistive controls. This controller also can be connected at the parallel port of JoyCon Exc without resistive button PCB.
[CPJexr]Where to get the signal of steering wheel controls
Knowledge Note KN1044 CarPC JoyCon Exr(Ex) Where to get the signal of steering wheel control? When you install CarPC JoyCon Exr(Ex) on your vehicle, you need to get the signal wires of steering wheel controls. There is two point where you can get the signal wire for CarPC JoyCon Exr(Ex). 1. From clock spring 2.
[CPJexr]How to use BMW E90,E91,E81,E87 steering wheel controls for Car PC
Knowledge Note KN1043 CarPC JoyCon Exr(Ex) How to use BMW E90,E91,E81,E87 steering wheel controls for Car PC This is the BMW E90,E91,E81,E87 steering wheel controls connector, this connector is connected to the clock spring in the steering wheel, and the signal wires go to the control box. You can get the signal wires
[CPJexr]Pausing at BIOS screen of Intel D525MW
Knowledge Note KN1041 Car PC JoyCon Exr Pausing at BIOS screen of Intel D525MW When CarPC JoyCon Exr is connected to D525MW(intel mini ITX mainboard) with USB hub, BIOS screen is paused about 5 second in booting. It happens when CarPC JoyCon Exr is connected with USB hub. There is three solution for this
[CPJex]How to create new preset files for Centrafuse.
You can create a new preset file in the JoyCon Explorer. As the picture above, the buttons for edit preset file are Erase, New Preset, Open, Save, Save As. The buttons are similar with other windows applications. You can erase all the connections of buttons, make new preset file, open a preset file,
