[CPJexc]How to use VW(Volkswagen) MFSW both for CarPC and Stereo

- 02541

Application Note AN1052 How to use VW(Volkswagen) MFSW both for CarPC and Stereo CarPC JoyCon Exc + BSGc(Button Signal Generator CAN) 1. Wiring The signal of VW(Volkswagen) MFSW is CAN. You can get the CAN signal at the radio jack. Intercept the CAN wire with CarPC JoyCon Exc and BSGc. 2. Setup of CAN steering wheel

[CPJexc]How to use VW(Volkswagen) MFSW both for CarPC and Aftermarket Stereo

How to Exc

- 01462

Application Note AN1053 How to use VW(Volkswagen) MFSW both for CarPC and Aftermarket Stereo CarPC JoyCon Exc + BSGr(Button Signal Generator Resistive) 1. Wiring The signal of VW(Volkswagen) MFSW is CAN. You can get the CAN signal wire at the radio jack. 2. Setup of CAN steering wheel control buttons Check Setting and click CAN Scan,

[CPJexd/exr]Launch Button and Close Button

- 01473

Knowledge Note KN1051 CarPC JoyCon Exd/Exr Launch Button and Close Button JoyCon Explorer version later than 130614 is required to use Launch Button and Close Button option. The application that is associated with a preset can be launched when the preset is switched by Preset up/down button. But some applications need to be launched only

[CPJexd/exr]Using Rearview Camera with CPJexd , CPJexr

- 01826

Knowledge Note KN1050 CPJexd/CPJexr Using Rearview Camera You can use a typical USB cam as a rearview camera with CPJexr/CPJexd. Any USB camera or video capture device can be a rearview camera. Rearview camera works by the reversing light. Connect the reversing light wire to the channel C of CPJexr/CPJexd. Connect USB camera to the Car PC. You

[CPJexd/BSGr]Control both Aftermarket stereo and car PC with OEM steering wheel controls

- 08368

After car PC installation, the steering wheel controls need to be connected to car PC or car stereo. You don’t need to give up car stereo for car PC. You can use your steering wheel controls both for car PC and car stereo. This document explains about the resistive controlled car stereos. See

[CPJexr/exd]Block Channel A by Channel D option for stalk adaptor(PAC)

- 01026

Knowledge Note KN1048 Car PC JoyCon Exr/Exd Block Channel A by Channel D Block CH A by CH D option is useful when you use a stalk adaptor(eg. PAC) by ACC power but the car PC is powered by its own battery. The signal from the stalk adaptor is undetermined when the ACC

[CPJexd]BMW IBUS interface both for Car PC and BMW OEM radio (E39 E46 E45 E38 E36 E37 E38(Z3) E53 E83)

- 011592

BMW IBUS steering wheel controls can be used both for car PC and BMW OEM stereo with CarPC JoyCon Exd. (BMW E39 E46 E45 E38 E36 E37 E38(Z3) E53 E83) You do not need to give up BMW OEM stereo for car PC. You can preserve the steering wheel controller's original function(radio

[CPJexr]How CPJexr/exd/exc works at Android

- 03633

Knowledge Note KN1047 CPJexr How CPJexr works at Android You can control Android device with steering wheel controls by CPJexr. Android 3.1 or later version is required to use CPJexr in Android. Use USB OTG cable to connect CPJexr to Android device. Drag and drop a button to Remote controller to connect the button to the

[CPJex]Sony RM-X4S remote controller

- 07149

This is Sony remote controller RM-X4S that has 12 buttons. You can use it for Car PC(or Boat PC) with CarPC JoyCon Ex(Exr). Put 5.1k ohm between tip and ring, to use the album+/- buttons. Perform Auto-Detect in JoyCon Explorer.

[CPJexr]Using ATEN CS533 for bluetooth connection

- 01466

ATEN CS533 is a KM(keyboard/mouse) switch that switches the USB keyboard/mouse to one USB Port and two bluetooth Port. You can also use CS533 to connect CarPC JoyCon Exr to Android devices by bluetooth. Firmware update is required to 121227 version. Before you connect CarPC JoyCon Exr to CS533, you need to configure
